However, it involves more than just shapes. ĬAD software for mechanical design uses either vector-based graphics to depict the objects of traditional drafting, or may also produce raster graphics showing the overall appearance of designed objects. In mechanical design it is known as mechanical design automation ( MDA), which includes the process of creating a technical drawing with the use of computer software. Its use in designing electronic systems is known as electronic design automation ( EDA). The terms computer-aided drafting ( CAD) and computer-aided design and drafting ( CADD) are also used. CAD output is often in the form of electronic files for print, machining, or other manufacturing operations.
: 4 Designs made through CAD software are helpful in protecting products and inventions when used in patent applications. : 3 This software is used to increase the productivity of the designer, improve the quality of design, improve communications through documentation, and to create a database for manufacturing. A 2D CAD drawing A 3D CAD modelĬomputer-Aided Design ( CAD) is the use of computers (or workstations) to aid in the creation, modification, analysis, or optimization of a design. For other uses, see Cad (disambiguation) and CADD (disambiguation).
